    Customization G550S Hi Tensile Colorbond Steel Gutter Machines With PLC System

    Ask Lasest Price
    Brand Name : BMS
    Model Number : Roofing Gutter
    Certification : SGS,CE,ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 30set per month
    Delivery Time : 45-50days
    • Product Details
    • Company Profile

    Customization G550S Hi Tensile Colorbond Steel Gutter Machines With PLC System

    Customization G550S Hi-Tensile Colorbond Steel Gutter Machines With PLC System


    Machine workflow:


    Decoiler---Roll Forming Machine---Hydraulic Cutter---PLC Control System---Exit Rack


    Material: G550S Hi-Tensile Colorbond Steel


    Thickness:0.4-0.6mm

    Yield strength: G550

    Feeding width:150mm


    Decoiler:

    Capacity: Max. 5.0Tons

    Main motor:3KW

    Control:Electric cabinet

    Coil ID range:508±30mm

    Coil outer-diameter: Max.1200mm


    Main Roll Forming Machine:


    Feeding Device: With manual pre-cutter as follows for saving materials


    Roll forming machine combined with body frame, transmission mechanism and
    forming rollers, etc.


    a) Body frame made from H400 type steel by welding with beautiful appearance,
    natural ageing treatment and SR(stress relief) treatment.


    b)The body frame: shaft diameter 60mm, made from 45# steel, precision
    machined. The lower shaft is the main transmission by gear chain.


    c)Rollers manufactured from 40Cr steel, CNC lathes, hard Chrome Coated


    d)Transmission by motor driving, gear chain transmission, about 18-step to form
    Main Motor=7.5KW, Frequency speed control
    Forming speed of approx.12-15m/min


    e) All the screw bolts with grade 8.8(cheap factories use low grade 4.8) to ensure a fix
    the machine structure tightly and long life during the machine a long time running.


    Hydraulic Cutting device:


    Cutting typeStop to cutting
    Cutting MotorHydraulic cutting
    Hydraulic pump4KW
    Cutting pressure12-16Mpa
    Cutting tool materialMould steel Cr12Mov
